0.6/1kV Aerial Bundle Cable BS 7870

Low Voltage AL Conductor XLPE Insulated Aluminium Cable

Application

Aerial bundle cable (ABC) low voltage cable for overhead power distribution offering higher level of safety and reliability and lower power losses than bare conductors.

Share This Page

Aerial Cable /Service Drop Cable

Airport Lighting Cable

Bare overhead conductor

Concentric Service Cable

Control Cable

Installation/ Building Cable

Low Voltage Cable

Medium Voltage Cable

Solar Cable

Standards

BS 7870

Construction

Phase conductors: AAC

Insulation: XLPE, UV-resistant.

Neutral-supported：AAC

Core identification: Ribs or numbers or colors stripe.

Characteristics

Voltage rating: 0.6/1kV
Test voltage: 4kV, 5min no breakdown.
Operating temperature: -40°C to +90°C
Minimum laying/installation temperature: -20°C
Minimum bending radius: 12x OD (overall diameter)

Specifications

Number of Cores x Nominal Cross Section No.×mm²	Approx. Overall Diameter mm	Approx. Weight Kg/Km	Max. DC conductor resistance at 20℃ Ω/km	Minimum Breaking Load kN	Current Rating A
1×16 RM	8,0	74	1,910	2,5	72
1×25 RM	9,0	106	1,200	4,0	107
1×35 RM	10,5	138	0,868	5,5	132
1×50 RM	11,8	182	0,641	8,0	165
1×70 RM	13,0	252	0,443	10,7	205
1×95 RM	15,4	333	0,320	13,7	240
1×120 RM	17,0	408	0,253	18,6	290
1×150 RM	19,0	502	0,206	23,2	334
1×185 RM	21,0	611	0,164	28,7	389
1×240 RM	24,0	801	0,125	37,2	467
2×16 RM	15,6	147	1,910	2,5	72
2×25 RM	18,0	208	1,200	4,0	107
2×35 RM	20,0	277	0,868	5,5	132
2×50 RM	23,5	361	0,641	8,0	165
2×70 RM	25,4	505	0,443	10,7	205
2×95 RM	30,3	666	0,320	13,7	240
2×150 RM	38,0	1004	0,206	23,2	334
4×16 RM	18,8	286	1,910	2,5	72
4×25 RM	21,2	430	1,200	4,0	107
4×35 RM	24,1	553	0,868	5,5	132
4×50 RM	27,8	746	0,641	8,0	165
4×70 RM	31,8	1.009	0,443	10,7	205
4×95 RM	37,8	1.332	0,320	13,7	240
4×120 RM	54,4	1.632	0,253	18,6	290
4×50 + 1×25 RM	319	814	0,641/1,200	8,0/4,0	165/107
4×50 + 1×35 RM	319	845	0,641/0,868	8,5/5,5	165/132
4×70 + 1×25 RM	360	1105	0,443/1,200	10,7/4,0	205/107
4×70 + 2×25 RM	400	1217	0,443/1,200	10,7/4,0	205/107
4×95 + 1×25 RM	418	1438	0,320/1,200	13,7/4,0	240/107
4×95 + 2×25 RM	420	1544	0,320/1,200	13,7/4,0	240/107
4×120 + 1×25 RM	590	2050	0,253/1,200	18,6/4,0	290/107
