Voltage rating: 0.6/1kV
Test voltage: 3.5kV, 5min no breakdown.
Operating temperature:
PVC: -15°C to +70°C PE: -40°C to +70°C XLPE: -40°C to +90°C
Minimum laying/installation temperature:
PVC: 0°C PE: -20°C XLPE : -20°C
Minimum bending radius: 12 x OD (overall diameter)

Specifications

Type	Nom. conductor cross section mm2	Max. DC conductor resistance at 20℃ Ω/km	Min. insulation resistance MΩ· km		Approx.OD mm	Nominal Weight kg/km
Type	Nom. conductor cross section mm2	Max. DC conductor resistance at 20℃ Ω/km	70℃	90℃	Approx.OD mm	Nominal Weight kg/km
JKY(CU/PE)	1×16	1.198	0.0065	–	7.2	166
	1×25	0.749	0.0054	–	8.4	246
	1×35	0.54	0.0054	–	9.8	344
	1×50	0.399	0.0046	–	11.1	460
	1×70	0.276	0.004	–	12.8	650
	1×95	0.199	0.0039	–	14.8	897
	1×120	0.158	0.0035	–	16.2	1120
	1×150	0.128	0.0035	–	18.1	1380
	1×185	0.1021	0.0035	–	20.3	1735
	1×240	0.0777	0.0034	–	22.7	2250
JKYJ (CU/XLPE)	1×10	1.906	–	0.67	5.8	104
	1×16	1.198	–	0.65	7.2	166
	1×25	0.749	–	0.54	8.4	246
	1×35	0.54	–	0.54	9.8	344
	1×50	0.399	–	0.46	11.1	460
	1×70	0.276	–	0.4	12.8	650
	1×95	0.199	–	0.39	14.8	897
	1×120	0.158	–	0.35	16.2	1120
	1×150	0.128	–	0.35	18.1	1380
	1×185	0.1021	–	0.35	20.3	1735
	1×240	0.0777	–	0.34	22.7	2250
JKLY(AL/PE)	1×16	1.91	0.0065	–	7.2	68
	1×25	1.2	0.0054	–	8.4	96
	1×35	0.868	0.0054	–	9.8	131
	1×50	0.641	0.0046	–	11.1	170
	1×70	0.443	0.004	–	12.8	232
	1×95	0.32	0.0039	–	14.8	319
	1×120	0.253	0.0035	–	16.2	390
	1×150	0.206	0.0035	–	18.1	483
	1×185	0.164	0.0035	–	20.3	601
	1×240	0.125	0.0034	–	22.7	784
JKLYJ (AL/XLPE)	1×16	1.91	–	0.65	7.2	68
	1×25	1.2	–	0.54	8.4	96
	1×35	0.868	–	0.54	9.8	131
	1×50	0.641	–	0.46	11.1	170
	1×70	0.443	–	0.4	12.8	232
	1×95	0.32	–	0.39	14.8	319
	1×120	0.253	–	0.35	16.2	390
	1×150	0.206	–	0.35	18.2	483
	1×185	0.164	–	0.35	20.1	601
	1×240	0.125	–	0.34	22.8	784
JKLHY (AAAC/PE)	1×16	2.217	0.0065	–	7.2	68
	1×25	1.393	0.0054	–	8.4	96
	1×35	1.007	0.0054	–	9.8	131
	1×50	0.744	0.0046	–	11.1	170
	1×70	0.514	0.004	–	12.8	232
	1×95	0.371	0.0039	–	14.8	319
	1×120	0.294	0.0035	–	16.2	390
	1×150	0.239	0.0035	–	18.1	483
	1×185	0.19	0.0035	–	20.3	601
	1×240	0.145	0.0034	–	22.7	784
JKLHYJ (AAAC/XLPE)	1×16	2.217	–	0.65	7.2	68
	1×25	1.393	–	0.54	8.4	96
	1×35	1.007	–	0.54	9.8	131
	1×50	0.744	–	0.46	11.1	170
	1×70	0.514	–	0.4	12.8	232
	1×95	0.371	–	0.39	14.8	319
	1×120	0.294	–	0.35	16.2	390
	1×150	0.239	–	0.35	18.1	483
	1×185	0.19	–	0.35	20.3	601
	1×240	0.145	–	0.34	22.7	784
JKLGYJ (ACSR/XLPE)	10/2	2.706	0.0067	0.67	7	70
	16/3	1.779	0.0067	0.65	8.4	92
	25/4	1.131	0.0054	0.54	9.8	136
	35/6	0.823	0.0054	0.54	11	185
	50/8	0.5946	0.0046	0.46	12.9	246
	50/30	0.5692	0.0046	0.46	14.8	435
	70/10	0.4217	0.004	0.4	14.8	336
	70/40	0.4141	0.004	0.4	16.7	584
	95/15	0.3058	0.0039	0.39	17.5	459
	95/20	0.3019	0.0039	0.39	17.3	490
	95/55	0.2992	0.0039	0.39	19.7	805
	120/7	0.2422	0.0035	0.35	18.8	462
	120/20	0.2496	0.0035	0.35	19.4	552
	120/25	0.2345	0.0035	0.35	19.4	620
	120/70	0.2364	0.0035	0.35	21.5	1004
	150/8	0.1989	0.0035	0.35	20.7	562
	150/20	0.198	0.0035	0.35	21.4	657
	150/25	0.1939	0.0035	0.35	21.4	709
	150/35	0.1962	0.0035	0.35	21.9	789
	185/10	0.1572	0.0035	0.35	23.1	710
	185/25	0.1542	0.0035	0.35	23.9	839
	185/30	0.1592	0.0035	0.35	23.9	864
	185/45	0.1564	0.0035	0.35	24.5	987
	240/30	0.1181	0.0034	0.34	27.2	1090
	240/40	0.1209	0.0034	0.34	27.2	1131
	240/55	0.1198	0.0034	0.34	27.8	1280

0.6/1kV Aerial Insulated Cable GB/T12527
